Product Highlights Zimmer BT 6 Bench Drill
Precision drilling machine with very high concentricity, especially for precision engineering and electronics.
- 8 spindle speeds either 630-7100 rpm or
- or 900-10000 rpm
- or 1080-12000 rpm
Technical data Zimmer BT 6 bench drill
| Continuous drilling capacity in St 60 |
0,5 - 6 mm |
| Drilling power normal |
|
| Thread cutting capacity |
|
| Spindle |
B 12 or MK 1 |
| Drilling depth |
55 mm |
| Outreach |
180 mm |
| Distance spindle/table |
135 to 380 mm |
| Table surface |
220 x 285 mm |
| Column diameter |
75 mm |
| Total height |
max. 800 mm |
| Weight |
73 kg |
| Engine power |
0,37/0,6 kW |
We would be happy to advise you on the machine and the extensive range of accessories by telephone.
In addition, we can possibly arrange a desired on-site appointment by arrangement!
