Lumag BENZIN Hydraulic Wood Splitter HB-8N

Technical Facts Lumag BENZIN Hydraulic Wood Splitter HB-8N :

• Complies with the latest safety standards
• Vertical design with long-life 4-stroke petrol engine for
• splitting short wood
• New design on the splitting wedge for 30% faster splitting
• Sturdy, torsion-resistant steel construction
• User-friendly two-hand control
• Hand guard and flexible wood holding device
• With driving device as standard

Technical data Lumag BENZIN hydraulic log splitter HB-8N :

• Engine 4-stroke petrol engine LC G200F
• Engine power 4,1 kW
• Displacement 196 cm³
• Engine speed, max. 3600 1/min
• Fuel unleaded petrol
• Fuel tank capacity 3.6 l
• Oil tank capacity / engine oil 0.6 l / SAE10W-30 or 10W-40
• Splitting force 8t
• Splitting material diameter 80 - 350 mm
• Splitting length 250 - 550 mm
• Hydraulic oil capacity max. 4 litres (HLP46)
• Hydraulic pressure 28 MPa
• Working speed: 5.2 cm/s
• Reverse speed: 15 cm/s
• Dimensions (LxWxH) Splitting wedge raised 1120 x 840 x 1510 mm
• Weight (net / gross) 121 / 129 kg
• Packing dimensions (LxWxH) 690x640x1220 mm
