ELMAG SEDSSR 44WDE-AVR-DSE4520 - Stage 3A generator with KUBOTA engine V3800DIT (super soundproofed, rental version)
ELMAG SEDSSR 44WDE-AVR-DSE4520 - Stage 3A generator with KUBOTA engine V3800DIT (super soundproofed, rental version)
ELMAG SEDSSR 44WDE-AVR-DSE4520 - Stage 3A generator with KUBOTA engine V3800DIT (super soundproofed, rental version)

ELMAG SEDSSR 44WDE-AVR-DSE4520 - Stage 3A generator with KUBOTA engine V3800DIT (super soundproofed, rental version)

Product No.:
53490
2-4 days 2-4 days (abroad may vary)
  • Spare parts supply
  • Top quality
  • Happy customers
  • Secure payment
  • Authorized dealers

Delivery: If you need the item very urgently, please ask in advance for the exact delivery time.

Weight:
1200 kg per piece
36.831,90 EUR

19% VAT excl. Shipping costs

Ask about product
Description

Product Highlights ELMAG SEDSSR 44WDE-AVR-DSE4520 - Stage 3A generator with KUBOTA motor V3800DIT (super sound insulated, rental version)​

  • POWER GENERATOR SEDSSR 11 TO 250 KVA - MOBILE POWER

    SEDSSR - ideal for construction sites, events, rental! The extremely comprehensive standard equipment makes these ELMAG® generators a flexible companion for countless applications.

    Even the basic equipment leaves almost nothing to be desired. The extremely robust design thanks to the galvanised base frame with integrated sump tray, oversized tanks and integrated collision protection defies even the toughest construction site conditions.


Standard equipment ELMAG SEDSSR 44WDE-AVR-DSE4520 - Stage 3A generator with KUBOTA motor V3800DIT (super sound insulated, rental version)​

- Equipment: 2x 230 V Schuko 16A, 1x 230 V CEE 16A-3p, 1x 230 V CEE 32A-3p, 1x 400 V CEE 32A-5p, 1x 400 V CEE 63A-5p and direct outlet
- 12V electric start
- Shut down: emergency stop, magneto stop, low oil pressure, over temperature, low coolant level, low fuel level, overload, short circuit and FI 30mA-30A reg. (fixed value - not adjustable)
- Generator type: LEROY SOMER 42.3S5
- AVR regulation
- Protection class IP 23
- LS2-Tropicalised
- DSE4520
- Electronic speed control
- Voltmeter + changeover switch
- 3-ampere meter
- Frequency measurement device
- Hour meter
- Fuel gauge
- Switchboard lighting
- Earth spike
- Galvanised base frame with collision protection
- Large tank inside with sump tray
- Lifting device for fork lift trucks
- Transport safety
- Document holder
- Diesel pump
- Oil drain pump
- Water separator
- Sound insulation SS
- Lifting eye

Technical facts ELMAG SEDSSR 44WDE-AVR-DSE4520 - Stage 3A generator with KUBOTA motor V3800DIT (super soundproofed, rental version)​

  • Motors standard according to Stage 3A
  • Robust Zincor housing (galvanised) - powder-coated
  • Large lockable maintenance doors
  • Synchronous generator and AVR control as standard
  • Galvanised base frame with all-round 20 mm collision protection
  • Operating panel with DSE4520 digital control module and additional analogue instruments for load (A), voltage with changeover switch (3-phase), frequency and remote start connection
  • Extensive panel of sockets
  • Direct power output
  • Large internal series tanks with sump tray
  • Lockable control panel door
  • Forklift pockets and lifting eye​

Technical data ELMAG SEDSSR 44WDE-AVR-DSE4520 - Stage 3A generator with KUBOTA motor V3800DIT (super sound insulated, rental version)​

voltage - frequency
400/230 Volt - 50 Hz
Maximum power 3~400V
44 kVA
Continuous power 3~400V
40 kVA
Power 3~400V cont.
58 A
Maximum power 1~230V
15,4 kVA
Continuous power 1~230V
14,6 kVA
Power 1~230V cont.
61 A
Fuel type
Diesel
Speed
1500 rpm
Cooling
water-cooled
Motortype
Kubota V3800DIT
Emission standard
3A
Engine power
42 kW
Cubic capacity
3.769 cm³
Cylinders
4
Tank capacity
263 l
Consumption at 75% load
7,7 l/h
Running time per tank filling at 75% load
34,2 h
Dimensions LxWxH
209x101x147 cm
Weight (without fuel)
1.200 kg
Sound power according to RL 2000/14/EG, 2005/88/EG
91 LWA
Sound pressure level in 7m
66 dB(A)

Highest quality of ELMAG machines
Benefit from a 2-year guarantee from ELMAG

Accessories for ELMAG machines on request
