Main page » Metal » Sanding Machines » Belt Sanding Machine » ELMAG BSM 100x1220 N, 230 Volt belt grinder
ELMAG BSM 100x1220 N, 230 Volt belt grinder
Product highlights ELMAG BSM 100x1220 N, 230 Volt belt grinder
Universal and economical
BSM N belt grinders are universally applicable and offer many possibilities: Efficient deburring, chamfering, rounding, sharpening of tool edges, shaping of contours, surface grinding and finishing of surfaces.
BSM 100x1220 N
Horizontal belt sanding machine for light to medium-heavy sanding work, ideally suited for one-off production and small series in craft businesses and metal workshops.
BSM N belt grinders are universally applicable and offer many possibilities: Efficient deburring, chamfering, rounding, sharpening of tool edges, shaping of contours, surface grinding and finishing of surfaces.
BSM 100x1220 N
Horizontal belt sanding machine for light to medium-heavy sanding work, ideally suited for one-off production and small series in craft businesses and metal workshops.
Standard equipment ELMAG BSM 100x1220 N, 230 Volt belt grinder
- BSM Belt sander
- Drive wheel balanced
- Contact wheel balanced
- Quick belt tensioner
- Belt adjustment with fine adjustment
- Belt guide
- Belt protection cover removable
- Eye protection glass
- Grinding support
- Chip box with suction connection
- High-performance drive
- Robust sheet steel housing
- On/Off button
- Zero voltage release
- Tools/operating instructions/CE
- Drive wheel balanced
- Contact wheel balanced
- Quick belt tensioner
- Belt adjustment with fine adjustment
- Belt guide
- Belt protection cover removable
- Eye protection glass
- Grinding support
- Chip box with suction connection
- High-performance drive
- Robust sheet steel housing
- On/Off button
- Zero voltage release
- Tools/operating instructions/CE
Technical facts ELMAG BSM 100x1220 N, 230 Volt belt grinder
- Powerful - drive motor 1,500 W
- Easy to dose - grinding speed 19 m/s
- belt tension adjustable - with quick release
- Rapid belt change - loosening and tensioning with one turn of the lever
- Low-vibration concentricity - balanced contact and drive wheels with precision bearings
- Gradient free - belt adjustment with fine adjustment
- Optimum handling - with large grinding support
- Quick changeover to plane and surface grinding - with removable belt protection cover
- Clean - with suction connection Ø 34 mm, suitable for standard hose connection
- All-round protection - robust sheet steel housing, protective covers, spark protection, eye protection glass, zero voltage release, CE-compliant
- Sheet steel housing
Technical data ELMAG BSM 100x1220 N, 230 Volt belt grinder
- sanding belt width: 100mm
- surface grinding area: 100x280mm
- sanding belt length: 1220mm
- grinding speed: 19m/s
- Contact wheel diameter: 130mm
- suction diameter: 73mm
- Speed: 2850UpM
- Drive Motor power: 1500W
- Power supply: 230 / 50-60V/Hz
- length: 700mm
- width: 400mm
- height: 350mm
- weight: 35kg
Highest quality of ELMAG machines
Benefit from a 2 year ELMAG warranty
Accessories for ELMAG machines on request
