ELMAG 600/10/100 D Compressor MEISTER
Produkt-Highlights ELMAG 600/10/100 D Kompressor MEISTER
THE PROVEN ELMAG MASTER CLASS
Perfection in technology, function and design, high quality workmanship down to the smallest detail, robust, reliable and durable - it is not for nothing that MEISTER two-cylinder air compressors can be found in many commercial and industrial operations.
They are the first choice when it comes to the flexible, in-house use of compressed air for various craft activities or for powerful continuous operation on construction sites.
For applications with large compressed air requirements, such as painting large surfaces or sandblasting, a tank volume of at least 100 litres is recommended.
Perfection in technology, function and design, high quality workmanship down to the smallest detail, robust, reliable and durable - it is not for nothing that MEISTER two-cylinder air compressors can be found in many commercial and industrial operations.
They are the first choice when it comes to the flexible, in-house use of compressed air for various craft activities or for powerful continuous operation on construction sites.
For applications with large compressed air requirements, such as painting large surfaces or sandblasting, a tank volume of at least 100 litres is recommended.
Technical facts ELMAG 600/10/100 D Compressor MEISTER
- THE TOP seller at ELMAG!
- Operational reliability due to V-belt drive
- Plug-and-play' equipment with two quick-connect couplings
- CONDOR pressure switch for automatic on/off operation
- Motor protection switch
- Tank and system pressure gauges
- Filter pressure reducer 'FRM' with metal protection cage
- Safety valve
- Check valve
- Solid rubber wheels
- Ball valve for condensate drain
- Swivel castors with brake
- Powerful, two-stage, two-cylinder compressor for professional users
- Large buffer reserve, 100 litre tank volume
- Optimal compressor for
- rotating/impacting air tools
- the use of large paint or sandblasting guns
- Smooth-running two-cylinder block unit with two compression stages, intercooler & aftercooler
- Compressed air is cooled between the stages - thus improved efficiency!
- Higher pressure possible than with a single-stage unit
- Boiler coated on the inside (improved corrosion protection)
Technical data ELMAG 600/10/100 D Compressor MEISTER
- Effective delivery rate: 370 l/min
- Delivery rate according to VDMA 4362, measured at 80 % of the maximum pressure: Yes
- Suction capacity: 520 l/min
- Max. Operating pressure: 10 bar
- Oil lubricated: Yes
- Tank volume: 100 l
- Design: mobile
- Nominal motor power: 3 kW / 4 PS
- Electrical connection voltage / frequency: 400 V / 50 Hz V/Hz
- Sound pressure level (4 m): 74 dB(A)
- Compressor speed: 1,450 rpm
- Length: 113 cm
- Width: 53 cm
- Height: 91 cm
- Weight: 86 kg
Benefit from a 2-year warranty from ELMAG
Accessories for ELMAG machines on request
