DHM415400V Holzmann thickness planer

Product Highlights DHM415400V Holzmann thickness planer​

• ground thicknessing table to minimise friction
• Hand wheel for fine adjustment of the chip removal
• Precision bearings on the cutter head ensure perfect planing results
• powerful chain drive of the feed drive
• suction connection: 120mm
• ergonomic and high-quality workmanship
• max. planing width 405mm

Scope of delivery DHM415400V Holzmann thickness planer​

• Strip planer blade mounted (410 x 3 x 30mm);
• planing knife setting gauge

Technical data DHM415400V Holzmann thickness planer​

• Motor power S6 in W: 4000
• voltage: 400V / 3 / 50Hz
• feed speed: 6,5m/min

• Suction connection in mm: 120
• Installation dimensions in mm: 985 x 968 x 955
• Gross weight in kg: 272

• Thickness planer Table size in mm: 750 x 408
• Thickness planing max. chip removal in mm: 5
• passage height in mm: 220

• Planer shaft diameter in mm: 95
• Planer shaft speed in min-1: 4200
• Number of planing knives: 3

• Sound power level in dB(A): 108
• Sound pressure level in dB(A): 100.1
