Bernardo turning machine Proficenter 450 V
The machining centre Proficenter 450 V is serially equipped with a tiltable milling head. The solid construction makes this machine extremely accurate and guarantees precise work.Properties Bernardo turning machine Proficenter 450 V
- Direct current motor for ideal torque at lower speed
- High-quality roller bearings guarantees high spindle concentricity (≤ 0.015 mm)
- Complete with stepless speed adjustment and digital speed display
- Membrane keyboard ensures user-friendly operation
- Serially equipped with automatic longitudinal and cross feed
- Adjustable tailstock allows taper turning
- Solid machine bed with guideways
- Guideways adjustable by gibs
- Right and left turning of milling spindle as standard
- Milling head tiltable from -30° to +45°
- Milling spindle features fine feed
Standard accessories Bernardo turning machine Proficenter 450 V
- 3-jaw chuck 100 mm
- 4-way tool post holder
- Chuck guard
- Change gears
- 2 dead center
- Splash guard
- Digital speed indication
- Splash guard
- Drill chuck arbor MT 2 / B 12
- Drawbar M 10
- Drill chuck 1 - 12 mm, B 12
Technical specifications Bernardo turning machine Proficenter 450 V
|
Turning lathe |
|
|
Distance between centers |
450 mm |
|
Center height |
105 mm |
|
Swing over bed |
210 mm |
|
Spindle bore |
20 mm |
|
Taper at spindle bore |
MT 3 |
|
Speed range, stepless |
100 - 2000 rpm |
| Longitudinal feed |
0,045 / 0,126 mm/rev. |
|
Metric thread |
(17) 0,25 - 3 mm |
|
Inch thread |
(10) 8 - 24 threads/1" |
|
Travel of tailstock sleeve |
50 mm |
|
Taper of tailstock sleeve |
MT 2 |
|
Motor power output S1 100% |
1,0 kW / 230 V |
|
Motor power input S6 40% |
1,35 kW / 230 V |
|
Milling attachment |
|
|
Drill capacity in steel |
10 mm |
|
Face mill capacity max. |
20 mm |
|
End mill capacity max. |
10 mm |
|
Distance spindle to column |
170 mm |
|
Spindle speed, stepless |
100 - 2000 rpm |
|
Spindle taper |
MT 2 |
|
Mill head tiltalbe |
-30° to +45° |
|
Mill head height adjustable |
170 mm |
|
Motor power output S1 100% |
0,15 kW / 230 V |
|
Motor power input S6 40% |
0,20 kW / 230 V |
|
Machine dimension (W x D x H)* |
1010 x 640 x 850 mm |
|
Weight approx. |
134 kg |
without stand
