Bernardo semi-automatic sawing machine MSB 440 DGH
The model MSB 440 DGH is a semi-automatic double mitre saw for mitre cutting up to 60°. The stepless cutting speed and the hydraulic vice ensure comfortable working. The application area of this machine is predominantly targeted at locksmith's shops, repair shops and tool construction.
Features Bernardo semi-automatic sawing machine MSB 440 DGH
- Cutting of pofiles, pipes, full rivet iron and non-ferrous materials
- The semi-automatic function increases productivity
- Complete with hydraulic vice for easy clamping of the workpiece
- Stepless cutting speed for optimal adjustment to the workpiece
- A manometer assures accurate blade tension
- Automatic regulation of the cutting pressure
- Saw frame swings to both sides for mitre cutting up to 60°
- Robust and vibration-free construction for professional use
Semi-automatic operating mode:
- Hydraulic clamping of the vice
- Hydraulic lowering of the saw frame
- Lifting of the saw frame
Standard accessories Bernardo semi-automatic sawing machine MSB 440 DGH
- Bandsaw blade
- Material fence
- Manometer for blade tension
- Hydraulic vice
- Coolant device
- Hydraulic cylinder
- Motor protective switch
- Automatic cutting pressure regulation
- Automatic shut-off
Technical specifications Bernardo semi-automatic sawing machine MSB 440 DGH
| Cutting capacity round / square 90° | 440 mm / 440 x 440 mm |
| Cutting capacity flat 90° | 610 x 440 mm |
| Cutting capacity round / square 45° | 410 mm / 410 x 410 mm |
| Cutting capacity flat 45° | 440 x 410 mm |
| Cutting capacity round / square 60° | 320 mm / 290 x 290 mm |
| Cutting capacity flat 60° | 440 x 290 mm |
| Working height | 860 mm |
| Cutting speed, stepless | 20 - 100 m/min |
| Bandsaw blade dimensions | 5200 x 34 x 1,1 mm |
| Coolant pump | 120 W |
| Motor power | 3,0 kW |
| Machine dimensions (L x D x H) | 2800 x 1210 x 1870 mm |
| Weight approx. | 1500 kg |
