Bernardo planing machine SP 150 P - 400 V
Properties Bernardo planing machine SP 150 P - 400 V
- Cutterblock features HSS-planing knives
- Ideal for planing of boards, planks etc.
- Most accurate grey cast iron planing tables guarantees excellent results
- Extremely long planing tables with ground surface assure perfectly smooth results
- On/Off button with undervoltage release
- Solid cast iron planing fence, tiltable from 90° to 45°
- Handwheel allows easy adjustment of chip removal
- Solid construction eliminates vibrations
Standard accessories Bernardo planing machine SP 150 P - 400 V:
- Cutter knives in HSS-Quality
- Knife gauge
- 2 x push handle
Technical specifications Bernardo planing machine SP 150 P - 400 V:
|
Planing width |
150 mm |
|
Table length |
1195 mm |
|
Table height |
820 mm |
|
Infeed table length |
585 mm |
|
Outfeed table length |
580 mm |
|
Planer fence |
730 x 95 mm |
|
Cutter knives |
3 pcs. |
|
Planer shaft diameter |
61 mm |
|
Shaft rotation speed |
4800 rpm |
|
Max. cutting depth |
8 mm |
|
Dust extraction outlet |
100 mm |
|
Motor power output S1 100% |
0,75 kW (1,0 HP) |
|
Motor power input S6 40% |
1,1 kW (1,5 HP) |
|
Voltage |
400 V |
|
Machine dimension (L x W x H) |
1195 x 530 x 1150 mm |
|
Weight approx. |
105 kg |
