Bernardo milling machine UWF 95 N
The UWF 95 N is an upgrade of the approved classic UWF 90, featuring an enhanced table size to extend applications area. Users enjoy high comfort levels achieved in part by the automatic drill feed. Additionally, this machine features an x-axis travel of 1000 mm as well as a pneumatic tool clamp device.
Features Bernardo milling machine UWF 95 N
- Automatic table feed (8 steps) in all axis
- Large table (1325 x 320 mm) includes T-slots
- Complete with 3-axis digital readout for maximum productivity
- Additional horizontal spindle extends application area
- Automatic spindle feed (0,08 - 0,25 mm) comes standard
- Positioning motor at z-axis (670 mm/min) comes standard
- Wide range of accessories standard
- Polished gear wheels, in oil bath, ensure smooth running
- Large rectangular guide at y- and z-axis
- Solid, grey cast-iron machine stand eliminates vibrations
- Left and right rotation allows thread cutting
Standard accessories Bernardo milling machine UWF 95 N
- 3-axis digital readout
- Drawbar M 16
- Pneumatic tool clamping (DIN 2080)
- Horizontal counter bearing
- Long milling arbor ISO 40/27mm, ISO 40/40 mm
- Adapter ISO 40/MT 4, ISO 40/MT 3, ISO 40/MT 2
- Coolant device
- Adjustable protective device
- Protective cover for horizontal milling
- LED machine light
Technical specifications Bernardo milling machine UWF 95 N
| Table size | 1325 x 320 mm |
| Spindle taper | ISO 40 |
| Spindle speed vertical | (8) 90 - 2000 rpm |
| Spindle speed horizontal | (12) 40 - 1300 rpm |
| Spindle stroke | 120 mm |
| Spindle feed | 0,08 / 0,15 / 0,25 mm/rev. |
| Travel (x / y / z) | 1000 / 290 / 400 mm |
| Distance spindle to column | 150 - 770 mm |
| Table tiltable | -45° to +45° |
| Spindle head tilting range | -90° to +90° |
| Distance spindle / table | 120 - 520 mm |
| Feed range longitudinal | (8) 22 - 420 mm/min |
| Feed range cross | (8) 22 - 393 mm/min |
| Feed range vertical | (8) 6 -112 mm/min |
| Rapid feed x-, y- and z-axis | 1290 / 1208 / 513 mm/min |
| T-slot size | 14 mm |
| Motor power vertical | 2,2 kW |
| Motor power horizontal | 2,2 kW |
| Machine dimensions (W x D x H) | 2030 x 1960 x 2400 mm |
| Weight approx. | 2175 k |
