The significant advantage of these automatic metal bandsaws is the polished double column which feeds the saw arm. Therefore these machines are ideal for machining solid block material. The large cutting capacity makes these models suitable for tool shops through to industrial production.
Properties Bernardo fully automatic sawing machine MSB 325 VC
- Fully automated model, including automatic lifting of saw arm
- Feed length of workpiece can be manually adjusted
- Motorized rollers in vice allow for material feed
- Complete with top clamping device – ideal for cutting of multiple workpieces
- Stepless speed setting, ideal for different materials
- Increased stability due to precisely polished linear guide for parallel cuts
- Automatic blade break control stops machine in case of blade break
- Programming the number of pieces is ideal for serial cuts
- Complete with manometer for ideal adjustment of belt tension
Standard accessories Bernardo fully automatic sawing machine MSB 325 VC
- Bandsaw blade
- Material fence
- Manometer for blade tension
- Hydraulic vice
- Coolant device
- Hydraulic cylinder
- Motor protective switch
- Automatic blade break control
- Automatic shut-down
- Top clamping
- Roller table
Technical specifications Bernardo fully automatic sawing machine MSB 325 VC
|
Cutting capacity round 90° |
325 mm |
|
Cutting capacity flat 90° |
350 x 325 mm |
|
Cutting capacity square 90° |
325 x 325 mm |
|
Working height |
580 mm |
|
Cutting speed, stepless |
20 - 100 m/min |
|
Bandsaw blade dimensions |
4160 x 34 x 1,1 mm |
|
Coolant pump |
250 W |
|
Motor power |
2,2 kW |
|
Machine dimensions (L x D x H) |
2450 x 900 x 1500 mm |
|
Weight approx. |
880 kg |
