Bernardo Feeding apparatus AF 308
Properties Bernardo Feeding apparatus AF 308
- Optimal to use in conjunction with small sized wood processing machines
- Complete with right and left turning device
- Rearranging the gear wheels allows for easy speed change
- Allows for individual settings for various work requirements
- Metal gearbox features hardened gear wheels
- Tiltable in any direction
- Continuous feeding speed, even at heavy load
- Complete with stand and extended bracket
Technical specifications Bernardo Feeding apparatus AF 308:
|
Feeding speeds |
2,9 / 4,5 / 5,8 / 7,5 / 9 / 11,5 / 15 / 23 m/min |
|
Rollers |
3 pcs. |
|
Roller diameter |
100 mm |
|
Roller width |
50 mm |
|
Roller suspension |
24 mm |
|
Motor power |
0,37 kW (0,50 HP) |
|
Voltage |
400 V |
|
Weight approx. |
50 kg |
