Bernardo Extraction system with fine dust filter cartridge DC 550 CF
Properties Bernardo Extraction system with fine dust filter cartridge DC 550 CF
- Cartridge filter come standard
- Requires minimum space but features top performance
- Ideal tool for extraction of sawdust, milling chips and wood shavings
- Increases performance of wood working machines significantly
- Strap with quick clamping allows for straightforward change of dustbag
- Solid steel sheet construction reduces static charge contrary to plastic housings
Standard accessories Bernardo Extraction system with fine dust filter cartridge DC 550 CF:
- Cartridge filters FP 2
- Waste bags
- Adapter 1 x 150 mm / 3 x 100 mm
- Carriage
Technical specifications Bernardo Extraction system with fine dust filter cartridge DC 550 CF:
| Capacity max. | 4400 m³/h |
| Filter area | 8,0 m2 |
| Low pressure max. | 1800 Pa |
| Inlet diameter | 1x 150 / 3 x 100 mm |
| Waste bag volume | 2 x 300 l |
| Idle speed | 2950 rpm |
| Sound pressure | 89,4 dB |
| Motor power output S1 100% | 2,2 kW (3,0 HP) |
| Motor power input S6 40% | 3,0 kW (4,2 HP) |
| Voltage | 400 V / 50 Hz |
| Machine dimension (W x D x H) | 1150 x 730 x 2030 mm |
| Weight approx. | 67 kg |
