Load capacity
1500 kg
Load centre
600 mm
Lifting heigth min.
85 mm
Max. lifting height
3000 mm
Fork length
1140 mm
Fork width
180 mm
Fork heigth
60 mm
Support width
570 mm
Clear fork width
210 mm
Turning radius
1280 mm
Lifting speed with load / without load
65 / 100 mm/sec.
Lowering speed with load / without load
85 / 70 mm/sec.
Swivel castor dimensions
Ø 180 x 50 mm
Fork roller dimensions
Ø 74 x 70 mm
Wheelbase
1160 mm
Hoist motor
1,5 kW
Battery voltage
12 V
Length
1720 mm
Width
780 mm
Height (mast retracted / extended)
2030 / 3520 mm
Weight incl. battery
543 kg
