The disc sander CB 600 is ideally suited for sanding wood, plastics, steel and non-ferrous metals. This model is mainly used by professional users.
Features Bernardo CB 600 disc sander
- With 100 mm extraction nozzle as standard for connection of an extraction system
- Balanced aluminium disc for vibration-free operation
- Heavy machine stand in torsion-free design
- The grinding table is mounted below the centre for optimal use of the grinding wheel
- Cast iron table with T-slot for mounting the mitre fence
- Powerful drive motor for best sanding results even during longer use
Scope of delivery Bernardo CB 600 disc sanding machine
- Grinding wheel
- Mitre fence
- Mechanical brake
- Underframe
Available special accessories Bernardo CB 600 disc sanding machine
- Sanding disc
- Abrasive belt cleaner (Art. No.: 11-2175)
Technical data Bernardo CB 600 disc sander
|
Grinding disc
|
600 mm
|
|
Number of grinding discs
|
1
|
|
Table dimensions
|
700 x 300 mm
|
|
Table swivelling
|
-45° bis +45°
|
|
Working height
|
900 mm
|
|
Speed
|
940 rpm
|
|
Suction connection Ø
|
100 mm
|
|
Engine power
|
1,5 kW
|
|
Voltage
|
400 V
|
|
Machine dimension (W x D x H)
|
640 x 700 x 1285 mm
|
|
Weight approx.
|
110 kg
|
