Bernardo CNC Lathe CK 360x500

24.347,90 EUR

Description

Product features Bernardo CNC lathe CK 360x500

With electronic handwheel as standard for manual traverse in x- and z-axis.
Both axes equipped with AC servo motors and ball screws
Wide cross slide to accommodate various steel holder systems
Stable tailstock with hydraulically adjustable tailstock spindle
High rapid traverse speed to reduce non-productive time
Main drive and feed drives driven by brushless AC motors
Main spindle with preloaded precision angular contact ball bearings guarantees high accuracy
User-friendly and easy-to-learn Siemens 808D Advanced control system
Sturdy spindle head with precision-bearing main spindle (spindle bore 60 mm)

Peak width	500 mm
Centre height	180 mm
Swing diameter over bed	360 mm
Swing diameter over cross slide	150 mm
Bed width	260 mm
Spindle bore	60 mm
Spindle mount	A2-6
Speed range, infinitely variable	150 - 2500 rpm
Travel x-axis	180 mm
Travel z-axis	500 mm
Rapid traverse x- / z-axis	4 / 7 m/min
Pinole diameter	50 mm
Pinole path	100 mm
Spindle sleeve holder	MK 4
Motor output power S1 100%	3,7 kW
Motor input power S6 40%	5,1 kW
Weight approx.	1350 kg
