Bernardo Centrifugal fan SF 3000 B
Properties Bernardo Centrifugal fan SF 3000 B
- Effective extraction at various applications, such as exhaust systems and ventilation technology
- Ideal for extracting dust, chippings, smoke, grains, wood and plastic particles etc.
- Curved fanwheels ensure high energy-efficiency and low noise levels
- High-quality powder coating creates scratch-resistant surface
- Optimized construction guarantees top performance
Standard accessories Bernardo Centrifugal fan SF 3000 B
- Base plate with frame
Technical specifications Bernardo Centrifugal fan SF 3000 B
|
Capacity max. |
4020 m³/h |
|
Low pressure max. |
1745 Pa |
|
Inlet diameter |
180 mm |
|
Outlet diameter |
180 mm |
|
Idle speed |
2860 rpm |
|
Motor power |
1,5 kW (2,0 HP) |
|
Voltage |
400 V / 50 Hz |
|
Dimension (W x D x H) |
712 x 693 x 690 mm |
|
Weight approx. |
52 kg |
