Bernardo belt and disc sanding machine BDSM 230 C
Properties Bernardo belt and disc sanding machine BDSM 230 C
- Graphite coating on belt sanding surface improves sliding capacity of sanding belt
- Set screws ensure convenient adjustment of parallel belt run
- High belt speed guarantees great sanding performance
- Universally applicable for sanding of edges, surface and for round grinding
- Spring balanced clamping device allows for even belt tension
- Solid, torsion-free machine housing ensures for a smooth run, free from vibrations
- Quick conversion from vertical to horizontal sanding position
- Sanding disc table can also be used for belt sanding operations
Standard accessories Bernardo belt and disc sanding machine BDSM 230 C:
- Sanding belt 1220 x 150 mm - grit 80
- Sanding disc diam. 230 mm - grit 80
- Mitre fence
- Workpiece fence
- Dust extraction outlet 50 mm
- Fence at belt sanding table
- Graphite coating
- Stand
- Tools
Technical specifications Bernardo belt and disc sanding machine BDSM 230 C:
|
Sanding belt |
1220 x 150 mm |
|
Belt sanding table |
435 x 165 mm |
|
Belt sanding table tiltable |
0° to 90° |
|
Sanding disc diam. |
230 mm |
|
Sanding disc table |
310 x 155 mm |
|
Sanding disc table tiltable |
0° to 45° |
|
Belt speed |
5,5 m/sec. |
|
No load speed |
1420 rpm |
|
Dust extraction outlet |
2x 55 mm |
|
Motor power output S1 100% |
0,75 kW |
|
Motor power input S6 40% |
1,1 kW |
|
Voltage |
230 V |
|
Machine dimension (W x D x H) |
730 x 500 x 1000 mm |
|
Weight approx. |
49 kg |
