Features Bernardo automatic switch-on ALV 10
When the woodworking machine is switched on or off, the extraction system is switched on or off with a time delay.
- For machines up to 4,0 kW motor power with 230 V resp. 400 V
Technical data Bernardo automatic switch-on ALV 10
|
Network data
|
3 / N / PE, 400 / 230 V / 50 Hz
|
|
Total connected load
|
Min. 100 W (response threshold), max. 400 V / 16A / 11100 W
|
| Sockets delayed |
|
|
Breaking capacity AC-1
|
230 V / 400 V / 16A
|
|
Breaking capacity AC-3
|
230 V / 13.5A / 3 kW or 400 V / 9A / 4 kW
|
|
Mains input
|
Plug collar CEE 5-pole, 3P+N+E, 16A, 6h with phase inverter adjustable from the front with screwdriver
|
| Outputs |
|
|
Master
|
1 socket CEE 5-pole, 3P+N+E, 16A, 6h + 1 socket Schuko 2P+E, 16A
|
|
Slave (delayed)
|
1 socket CEE 5-pole, 3P+N+E, 16A, 6h + 1 socket Schuko 2P+E, 16A
|
|
Protection class
|
IP 44 (protection against dust deposits and splash water)
|
|
Mounting housing
|
4 bushes M5 - 68 x 68 mm at the bottom of the enclosure
|
|
Material / Colour
|
ABS / grey housing, polyamide PA / red plug collar and CEE socket, black earthed sockets
|
|
Dimensions (L x W x H)
|
245 x 123 x 153 mm
|
|
Weight approx.
|
1250 g
|
