Bernardo AT 1500 HM grinding dust extraction table

Product No.:
12-2197
2-4 days 2-4 days (abroad may vary)
  • Spare parts supply
  • Top quality
  • Happy customers
  • Secure payment
  • Authorized dealers

Delivery: If you need the item very urgently, please ask in advance for the exact delivery time.

1.990,46 EUR

19% VAT excl. Shipping costs

Ask about product
Description

Features Bernardo AT 1500 HM grinding dust extraction table​

  • Professional execution - ensures optimal working conditions and clean air in the workplace
  • Optimal filtering of the suction air, which is returned to the working area in a recirculation process
  • High efficiency and quiet running due to optimally matched fan shape
  • Suitable for grinding all types of parts
  • Extendable dust collection container at the front of the machine
  • Standard with fold-down side plates for longer workpieces
  • Built-in ventilator, therefore no additional exhaust system necessary
  • Rubber table supports guarantee scratch-free work
  • Steel fan wheel, statically and dynamically balanced

Scope of delivery Bernardo AT 1500 HM grinding dust extraction table​

  • On-Off switch
  • 4x filter (wood / metal)
  • Rubberised table support
  • Chip tray
  • 6x workpiece stop

Technical data Bernardo AT 1500 HM grinding dust extraction table​

Table size

1550 x 550 mm

Table height

825 mm

Load capacity max.

225 kg

Volume flow max.

2x 2500 m³/h

Engine power

2x 0,75 kW (2x 1,0 PS)

Voltage

230 V / 50 Hz

Machine dimensions (W x D x H)

1660 x 620 x 900 mm

Weight

105 kg
